Compact Stacker 2.0T

Engineered for precision and efficiency in material handling, excels in space-constrained environments.

Compact Stacker 2.0T
Compact Stacker 2.0T
Compact Stacker 2.0T
Compact Stacker 2.0T
Compact Stacker 2.0T
Compact Stacker 2.0T
Compact Stacker 2.0T
Compact Stacker 2.0T

Precision Motion Control

Servo System

Compact Navigation

Narrow Aisle 2m±

Versatile Handling

Open Pallets/Cage/Racks

Proven Drive Systems

Curtis/ZAPI/Kinco Drive

Advanced Positioning

Encoder Options

Smart Detection

Pallet Recognition Sensor Optional

ModelAB-FLB-CS20
Feature
Power TypeElectric
Driving StyleAGV
Rated Load Capacity (Q)2000 kg
Load Center Distance (C)600 mm
Front Suspension Distance (x)649 mm
Wheelbase (y)1056 mm
Weight
Self Weight (Including Battery)1200 kg
Axle Load (Full Load), Driving Side/Load-Bearing Side1020/2180 kg
Axle Load (Empty load), Driving Side/Load-Bearing Side940/260 kg
Wheel
Tire TypePolyurethane
Tire Size, Drive WheelΦ230×75 mm
Tire Size, Load-Bearing WheelsΦ80×65 mm
Tire Size, Balance WheelΦ115×55 mm
Number Of Wheels, Drive Side (x=Drive Wheels)/Load-Bearing Side1x-2/4
Front Wheel Track, Drive Side (b10)630 mm
Rear Wheel Track, Load-Bearing Side (b11)500 mm
Basic Dimensions
Total Height (h1)2235 mm
Total Width1121 mm
Total Length (L1)1896 mm
Vehicle Length (Excluding Fork) (L2)726 mm
Free Lifting Height (h2)0 mm
Lifting Height (h3)2500mm/5500 mm
Extended Mast Max. Height (h4)3580 mm
Fork Surface Minimum Height (When The Fork Is At Its Lowest)   (h5)85 mm
Charging Pad Height (h6)500 mm
Fork Size (l/e/s)1150/180/75 mm
Fork Outer Width (b5)680 mm
Min. Ground Clearance (m1)31 mm
Min. Turning Radius (Wa)1440 mm
Min. Right Angle Stacking Aisle Width2060+200 mm
Right Angle Stacking Aisle Width, Pallet 800×1200 (1200 Placed Along The Fork)/
Right Angle Stacking Aisle Width, Pallet 1000×1000 (1200 Placed Along The Fork)/
Right Angle Stacking Aisle Width, Pallet 1000×1200 (1200 Placed Along The Fork)2185+200 mm
Performances
Driving Speed, Full load/Empty Load5/5 km/h
Lifting Speed, Full Load/Empty Load90/120 mm/s
Descent Speed, Full load/Empty load120/110 mm/s
Climbing Performance, Full Load/Empty Load3%/5%
Driving Brake ModeElectromagnetic braking
Motion
Drive Motor Power1.5 kw
Power of Lifting Motor3.0 kw
Steering Motor Power0.4 kw
Drive Motor Type24 V asynchronous AC motor
Steering Motor Type24 V DC Servo motor
Lifting MechanismHydraulic control
Communication ProtocolCAN
Battery
Weight of Battery58 kg
Battery TypeLithium iron phosphate
Battery Voltage/Rated Capacity24/210 V/Ah




Frequently Asked Questions

What is the PCOPCO Compact Stacker 2.0T?

This is a stacker truck AGV component under the PCOPCO brand. It integrates vertical lifting and pallet handling functions for automated industrial material transport. It is designed as a compact, space-efficient solution for warehouse and workshop operations.

What are the key technical specifications of the PCOPCO Compact Stacker 2.0T?

The PCOPCO Compact Stacker 2.0T has a rated load capacity of 2000kg and a maximum lifting height of 3000mm. It is equipped with a 24V210Ah battery and supports BMS communication via either RS485 or CAN interfaces. These parameters meet most standard industrial material handling requirements.

What industrial applications is the PCOPCO Compact Stacker 2.0T suitable for?

This PCOPCO AGV component is ideal for automated warehouses, manufacturing workshops and logistics distribution centers. It can efficiently move palletized goods between storage racks and production lines. Its compact design allows it to operate smoothly in narrow aisle spaces.

How does the PCOPCO Compact Stacker 2.0T compare to similar AGV components?

Compared to competing stacker AGV components, the PCOPCO model offers flexible BMS communication options for seamless integration with existing control systems. Its 24V210Ah battery delivers reliable runtime between charges. The compact footprint also makes it more adaptable to tight industrial workspaces than many larger alternatives.

What procurement notes should I consider for the PCOPCO Compact Stacker 2.0T?

Before purchasing, confirm your site’s required lifting height matches the unit’s 3000mm maximum lift. You can contact PCOPCO’s official sales team for custom configuration or after-sales support details. Also ensure the RS485/CAN communication interface is compatible with your existing AGV control system.

What is the PCOPCO Compact Stacker 2.0T?

The PCOPCO Compact Stacker 2.0T is a specialized stacker truck AGV component under PCOPCO’s industrial product lineup. It integrates lifting and transporting functions for automated material handling of palletized goods, targeting compact industrial workspaces where traditional forklifts face maneuverability limits.

What are the core technical parameters of the PCOPCO Compact Stacker 2.0T?

This PCOPCO AGV component has a rated load capacity of 2000kg and a maximum lifting height of 3000mm. It is equipped with a 24V210Ah battery for sustained operational runtime, and supports BMS communication via both RS485 and CAN interfaces for seamless integration with industrial control systems.

In which industrial scenarios is the PCOPCO Compact Stacker 2.0T suitable?

The PCOPCO Compact Stacker 2.0T is ideal for narrow-aisle logistics warehouses, compact automotive parts workshops and electronics assembly plants. It excels at automated pallet stacking and transportation, especially for sites with limited space that require unmanned material handling operations. It also fits bulk goods distribution centers with regular material handling needs.

How does the PCOPCO Compact Stacker 2.0T compare with similar AGV stacker components?

Compared with many generic AGV stacker components, the PCOPCO Compact Stacker 2.0T offers dual BMS communication protocols for broader compatibility with existing industrial control systems. Its 24V210Ah battery also delivers longer continuous runtime under full load than most comparable models. Additionally, its compact design enhances maneuverability in tight workspace layouts.

What key considerations should I have when purchasing the PCOPCO Compact Stacker 2.0T?

First, confirm that the product’s rated load capacity and maximum lifting height match your site’s specific material handling requirements. You should also check the compatibility of its RS485/CAN BMS communication with your factory’s existing automation systems. It is recommended to consult PCOPCO’s authorized distributors for pre-purchase verification and customized integration support.

What exactly is the PCOPCO Compact Stacker 2.0T Industrial AGV component?

The PCOPCO Compact Stacker 2.0T is a purpose-built stacker truck AGV component for industrial automated material handling. It belongs to the Industrial AGV components category, designed to handle pallet stacking and transport tasks across factory and warehouse environments.

What are the core technical specifications of the PCOPCO Compact Stacker 2.0T?

This unit has a rated load capacity of 2000kg and a maximum lifting height of 3000mm, suitable for mid-range heavy lifting tasks. It is equipped with a 24V210Ah battery and supports BMS communication via RS485 or CAN interfaces for seamless system integration.

In which industrial scenarios is the PCOPCO Compact Stacker 2.0T most applicable?

It is ideal for narrow-aisle high-density warehouses, manufacturing workshop material handling, and e-commerce distribution centers. The compact design of the PCOPCO stacker AGV component allows efficient operation in space-constrained material handling environments.

How does the PCOPCO Compact Stacker 2.0T stack up against similar AGV components on the market?

Compared to competing models, the PCOPCO Compact Stacker 2.0T offers reliable battery life and flexible communication options for broader system compatibility. Its industrial-grade build quality also ensures consistent performance in harsh workshop environments with lower long-term maintenance needs.

What should I confirm or prepare before purchasing the PCOPCO Compact Stacker 2.0T?

Buyers should first confirm compatibility between the device's communication protocols and their existing factory automation systems. PCOPCO also provides custom parameter adjustments and full technical documentation to support smooth post-purchase deployment and daily operation.

What is the PCOPCO Compact Stacker 2.0T AGV component?

The PCOPCO Compact Stacker 2.0T is a stacker truck AGV component designed for automated material handling and pallet stacking. It combines lifting and transportation functions to support unmanned workshop logistics workflows. This component is part of PCOPCO’s industrial AGV product lineup, tailored for compact industrial workspaces.

What are the core technical specifications of the PCOPCO Compact Stacker 2.0T?

The core technical specifications of this PCOPCO stacker AGV component include a rated load capacity of 2000kg, maximum lifting height of 3000mm, 24V210Ah battery, and support for both RS485 and CAN bus BMS communication. These parameters are optimized for mid-weight material handling tasks in manufacturing and logistics facilities. Users can select the appropriate communication protocol to match their existing automation systems.

What industrial applications is the PCOPCO Compact Stacker 2.0T suited for?

This PCOPCO Compact Stacker 2.0T is ideal for compact manufacturing workshops, warehouse pallet stacking and transfer, and automated assembly line material supply. It performs well in space-limited environments where manual operations are inefficient or labor-heavy. It can also integrate with existing conveyor systems to build a fully automated logistics chain.

How does the PCOPCO Compact Stacker 2.0T stack up against similar AGV stacker components?

Compared to generic stacker AGV components, the PCOPCO version offers dual BMS communication options (RS485 and CAN bus) for better compatibility with most industrial automation systems. Its 24V210Ah battery delivers longer continuous runtime for 2-ton rated load operations. Additionally, its compact frame design suits narrow workspace scenarios that many competing products struggle to adapt to.

What do I need to check before buying the PCOPCO Compact Stacker 2.0T AGV component?

Before purchasing the PCOPCO Compact Stacker 2.0T, you should confirm your site’s required lifting height, load matching needs, and existing automation system’s communication protocol for full compatibility. You can also consult PCOPCO’s technical team for customized solutions based on your workshop layout. It is recommended to order through authorized distributors to ensure genuine products and reliable after-sales support.
