A rugged, high-reliability safety interface built for AGVs.
Detailed technical specifications
Offers multiple color choices and various circuit configurations, allowing customized switch definitions
Made from high-quality PC flame-retardant materials to ensure safety and reliability during frequent use
Contacts self-clean to reduce dust and oxidation, maintaining excellent conductivity
Long service life with a high cost-performance ratio
Available in both self-locking and self-resetting push-button modes to meet diverse requirements
Certified by the European Union CE standards, guaranteeing quality and safety
Learn more about product details
| PCOPCO-MS-N× | PCOPCO-LS-N× | PCOPCO-MS-D× | PCOPCO-LS-D× | PCOPCO-MS-OC | PCOPCO-LS-OC | |
| Rated Voltage | 12V/24V | 12V/24V | 12V/24V | 12V/24V | 12V/24V | 12V/24V |
| Heating Current | 10A | 10A | 10A | 10A | 10A | 10A |
| Operating Frequency | 1200 times/h | 1200 times/h | 1200 times/h | 1200 times/h | 1200 times/h | 1200 times/h |
| Operating Temperature | -25 – 55 ℃ | -25 – 55 ℃ | -25 – 55 ℃ | -25 – 55 ℃ | -25 – 55 ℃ | -25 – 55 ℃ |
| Storage Temperature | -30 – 70 ℃ | -30 – 70 ℃ | -30 – 70 ℃ | -30 – 70 ℃ | -30 – 70 ℃ | -30 – 70 ℃ |
| Operating Humidity | 45% – 85% RH | 45% – 85% RH | 45% – 85% RH | 45% – 85% RH | 45% – 85% RH | 45% – 85% RH |
| IP Rating | IP54 | IP54 | IP54 | IP54 | IP54 | IP54 |
| Certification | CE | CE | CE | CE | CE | CE |
| LED | Optional | Optional | Optional | Optional | Optional | Optional |
| Contact Specification | NC/NO | NC/NO | 2*NC/2*NO | 2*NC/2*NO | NC&NO | NC&NO |
| Operating Characteristics | Momentary Switch | Latching Switch | Momentary Switch | Latching Switch | Momentary Switch | Latching Switch |
Frequently Asked Questions
This is a specialized emergency stop button switch designed for industrial Automated Guided Vehicle (AGV) components under the PCOPCO brand. It serves as a critical safety control component to enable immediate shutdown of AGVs during operational hazards.
The PCOPCO customized AGV button switch features a 22mm mounting hole size, with an extended length of 43mm behind the control panel. Its overall dimension is 40mm, and it has an IP65 protection rating, making it suitable for harsh industrial environments with dust or low-pressure water spray.
This PCOPCO emergency stop button is ideal for various industrial AGV setups, including warehouse logistics AGVs, automated assembly line transport vehicles, and factory floor material handling carriers. It can be mounted on AGV control panels or standalone emergency stop stations to enhance workplace safety.
Unlike generic industrial buttons, this PCOPCO product is purpose-built for AGV component requirements, with precise mounting dimensions tailored for AGV control systems. It also delivers consistent, reliable emergency stop performance backed by the PCOPCO brand’s industrial quality standards.
Yes, the PCOPCO customized button switch offers tailored solutions to match specific AGV project needs. You can adjust parameters or packaging based on your bulk order requirements for industrial AGV deployments.
