Platform Lifter 400kg

A versatile, autonomous lifting system capable of texture recognition and intelligent power management.

Platform Lifter 400kg
Platform Lifter 400kg
Platform Lifter 400kg
Platform Lifter 400kg
Platform Lifter 400kg
Platform Lifter 400kg
Platform Lifter 400kg
Platform Lifter 400kg

Precision Motion Control

Servo System

Agile Maneuvering

Differential Wheels

Reliable Drive Systems

Kinco/MOONS Drive

Accurate Positioning

Encoder Included

Long-Lasting Power

7-8h LFP Battery Life

Optimized Lifting

60mm Lifting Capability

ModelAB-FLB-PL04
Feature
Drive ModeDifferential drive of two wheels
Dimensions778×540×255 mm
Rotation Diameter778 mm
Self-Weight98 kg
Rated Load400 kg
Chassis Ground Clearance25 mm
Lifting Panel Size710×500 mm
Lifting Height60 mm
Motion
Rated Operating Speed (Rated Load/No Load)1.5 m/s; 1.9 m/s
Acceleration (Rated Load/No Load)0.3 m/s²; 0.6 m/s²
Rotation Speed (Full Load/No Load)100°/s; 200°/s
Battery
Battery TypeLithium iron phosphate
Capacity/Rated Voltage16 Ah/48V
Charge-Discharge Cycle Times1,500 times
Rated Working Condition Endurance Time6-8 h
Charging Time After Complete Discharge≤1.5 h
Communication ProtocolCAN/RS485
Other Parameters
Navigation ModeLaser SLAM or 2D code
Front Laser Obstacle Avoidance (Quantity/Installation Height)1 piece/220 mm
Opening Angle250°
Emergency Stop Buttons2 pieces (front and rear each 1)
Contact ProtectionPiezoelectric edge switch
Acoustic-Optic AlarmStandard
Chassis Damping ModeTwo-stage floating chassis
Climbing Capacity≤5%/3°
Step Capacity≤5 mm
Gutter Crossing Capacity≤30 mm
SignalSupports dual-band Wi-Fi (2.4 GHz and 5 GHz), with wireless signal strength ≥ -70 dBm.
HumidityRelative humidity 10%–90% without condensation
Temperature

Working area: -10°C–45°C

Charging area: 0°C–45°C




Frequently Asked Questions

What category is the PCOPCO Platform Lifter 400kg?

The PCOPCO Platform Lifter 400kg falls under Industrial AGV components, specifically as a platform-style AGV accessory. It is designed to integrate with automated guided vehicle systems for industrial material handling.

What technical specifications does the PCOPCO Platform Lifter 400kg have?

Its core specifications include a rated load capacity of 400kg, maximum lifting height of 60mm, 48 V 16 Ah LFP battery, and BMS communication support via RS485/CAN. These specs align with standard small-scale industrial lifting and handling requirements.

What industrial scenarios is the PCOPCO Platform Lifter 400kg suitable for?

This lifter works well for compact industrial workspaces, such as warehouse small-pallet handling, assembly line material shifting, and workshop equipment positioning. It excels at low-height lifting tasks for daily material movement.

How does the PCOPCO Platform Lifter 400kg compare to similar AGV platform lifters?

Compared to competing products, the PCOPCO Platform Lifter 400kg offers flexible BMS communication options to match most industrial control systems. It uses a safe LFP battery and delivers consistent rated load performance for reliable daily operations.

What should I confirm before purchasing the PCOPCO Platform Lifter 400kg?

Before ordering, you should verify that its BMS communication protocol is compatible with your existing industrial control system. You may also need to confirm delivery lead times and source through authorized PCOPCO distributors for genuine products.

What is the PCOPCO Platform Lifter 400kg?

The PCOPCO Platform Lifter 400kg is a specialized industrial automated guided vehicle (AGV) component. It functions as a lifting platform unit for AGV systems, supporting automated material handling in factory and warehouse settings.

What technical specifications does the PCOPCO Platform Lifter 400kg have?

This PCOPCO AGV component has a rated load capacity of 400kg and a maximum lifting height of 60mm. It is equipped with a 48 V 16 Ah LFP battery and supports RS485/CAN communication for its battery management system. These specs are optimized for precise, low-profile material lifting tasks.

What industrial applications is the PCOPCO Platform Lifter 400kg suitable for?

This PCOPCO lifting component is ideal for low-clearance material handling scenarios, such as electronics assembly lines and small-part warehouse stocking. Its compact 60mm max lift height allows it to operate in tight factory workspaces without disrupting existing production equipment.

How does the PCOPCO Platform Lifter 400kg compare to similar AGV lifting components?

Compared to many competing industrial AGV lifting parts, the PCOPCO Platform Lifter 400kg balances a 400kg rated load with a low 60mm maximum lift height for tight workspaces. It also uses a reliable LFP battery with dual communication protocols, enabling flexible integration with most standard AGV control systems.

What should I consider before purchasing the PCOPCO Platform Lifter 400kg?

Before buying this PCOPCO AGV component, first confirm its 400kg load capacity and 60mm max lift height match your material handling needs. You should also verify compatibility with your AGV system’s communication protocol, as it supports both RS485 and CAN bus. Authorized industrial automation distributors typically stock this product for standard delivery timelines.

What exactly is the PCOPCO Platform Lifter 400kg as an industrial AGV component?

This PCOPCO Platform Lifter 400kg is a dedicated platform-style industrial AGV component. It integrates lifting and precise positioning functions into automated guided vehicle systems for factory material handling. This component helps automate repetitive material transfer tasks in manufacturing facilities.

What technical specifications does the PCOPCO Platform Lifter 400kg have?

The PCOPCO Platform Lifter 400kg has a rated load capacity of 400kg and a maximum lifting height of 60mm. It is equipped with a 48 V 16 Ah LFP battery and supports BMS communication via RS485 or CAN interfaces. These specifications ensure compatibility with most standard industrial AGV control setups.

What industrial scenarios is the PCOPCO Platform Lifter 400kg AGV component suitable for?

This PCOPCO lifting component is ideal for small-to-medium scale automated material handling scenarios. It works well in manufacturing workshops, warehouses and component assembly lines for transporting small-to-medium workpieces or material bins. It also supports precise positioning tasks to streamline production workflows.

How does the PCOPCO Platform Lifter 400kg stack up against similar industrial AGV lifting components?

Compared to many generic industrial AGV lifting components on the market, the PCOPCO Platform Lifter 400kg offers reliable long-lasting LFP battery performance and flexible communication options. Its compact low-profile design with 60mm maximum lifting height suits tight-space material handling tasks. The brand’s consistent manufacturing standards also ensure stable long-term operational reliability.

What should I know before procuring and integrating the PCOPCO Platform Lifter 400kg AGV component?

You can source this component through authorized PCOPCO industrial automation distributors or contact the brand’s sales team for bulk procurement orders. Prior to integration, confirm that the component’s RS485/CAN BMS communication interfaces match your existing AGV system’s control requirements. It is also advisable to verify warranty terms and delivery lead times to align with your project timeline.

What is the PCOPCO Platform Lifter 400kg AGV component?

The PCOPCO Platform Lifter 400kg is a dedicated lifting component for industrial automated guided vehicles (AGVs). It adds automated lifting functionality to AGV systems for material transfer and positioning tasks. All units are built to meet strict industrial durability standards under the PCOPCO brand.

What are the core technical specifications of the PCOPCO Platform Lifter 400kg?

Its core specifications include a 400kg rated load capacity and 60mm maximum lifting height. It is equipped with a 48V 16Ah LFP battery and supports BMS communication via RS485 or CAN interfaces. These specs align with common industrial AGV integration requirements.

In which industrial scenarios can the PCOPCO Platform Lifter 400kg be used?

This component is suitable for light-to-medium material handling scenarios such as factory assembly lines, warehouse stocking and parts distribution workshops. It helps automate repetitive lifting tasks during AGV-based material transfers. It works well for handling small workpieces, palletized goods and standard industrial components.

How does the PCOPCO Platform Lifter 400kg stand out against competing AGV lifting components?

Compared to generic third-party lifting parts, the PCOPCO model is purpose-built for AGV integration. Its standardized communication interfaces and long-life LFP battery lower long-term maintenance costs. It also delivers precise lifting control to match automated material flow system needs.

Where and how can I purchase the PCOPCO Platform Lifter 400kg AGV component?

You can source the PCOPCO Platform Lifter 400kg through our global network of authorized industrial automation distributors. We offer pre-sales technical consultation to confirm compatibility with your existing AGV setup. Bulk orders also come with standard warranty coverage and compliance certificates for major regional markets.
