We provide full-series perception solutions including 2D/3D LiDAR, cameras, magnetic and RFID sensors to enable environmental awareness, precise positioning and safe operation for AGV robots.
High-quality, reliable robot core components
ModelPCOPCO-CM-3D-OR-iTofPerformance ParametersTechnologyToF (Time-of-flight) Depth CameraIllumination940 nm, 2 x 6 W Optical Power VCSELDepth Sensor Resolution and Frame rate640 x 480 @ 15 fpsRGB Sensor Resolution and Frame Rate1600x1200 @ 15 fpsToF HDR
View Details
ModelPCOPCO-CM-3D-OR-HDPerformance ParametersTechnical PrincipleActive stereoIllumination1 x Infrared laser (λ = 940 nm)Latency of Image Acquisition126 msDepth Sensor Resolution and Frame Rate16 fps @ 1280 x 96024 fps @ 640 x 48024 fps @ 320 x 240RGB Sen
View Details
ModelPCOPCO-CM-2D-QR-AGVPerformance ParametersFocal Length3.37 mmWork Distance100 mmFOV110 mm × 93 mmMax. Reading Speed125 codes per secondMax. Operating Speed3 m/sFocusing MethodFixed typeLight SourceWhite LEDDepth of Field±20 mmAngular Accuracy0.1°Disp
View Details
Model PCOPCO-LD-B01-R10-DRJ45 & PCOPCO-LD-B01-R10-DI/O Performan
View Details
Model PCOPCO-LD-B01-R05-DRJ45 & PCOPCO-LD-B01-R05-DI/O Perform
View Details
Model Specification Performance Parameters
View Details
Model Specification Performance Parameters
View Details
ModelPCOPCO-LD-B01-R50-DM12Performance ParametersDetection Distance0.05 m–20 m (reflectivity 2%)0.05 m–50 m (reflectivity 90%)Detection Angle360°(2D)Sampling Rate50K, 100K, 150K, 200KAngular Resolution0.018° (determined by scanning frequency, motor speed
View Details
ModelRange SlimPerformance ParametersDetection Distance0.05 m – 1.5 m (reflectivity 10%)0.05 m – 4 m (reflectivity 90%)Detection Angle120° (4-line vertical angle of 12 °)Scan Frequency10 Hz × 4Min. Resolution for Obstacle Detection0.5°Angle Resolutio
View Details
Greater Performance with Reduced Blind Spot Recommended Mounting Combinations The ultimate solution for the robotics industry
View Details
ModelPCOPCO-MG-CNS-MGS-160NDPerformance ParametersDetection Height10-50 m (CNS-MS-30N)Detection Range±75 mmDetection Accuracy1 mmNumber of Output Digital Quantity Points16 - bit digital quantityDistance Between Detection Points10 mmSensor Sensitivity0-9
View Details
ModelPCOPCO-MG-CNS-MLS-160NPCOPCO-MG-CNS-MLS-320NPCOPCO-MG-CNS-MLS-480NPCOPCO-MG-CNS-MLS-640NPerformance ParametersDetection Height0 - 50mm (@ 90 Gauss magnetic stripe)0 - 50mm (@ 90 Gauss magnetic stripe)0 - 50mm (@ 90 Gauss magnetic stripe)0 - 50mm (@ 90 Gauss mag
View Details
ModelPCOPCO-MG-CNS-MGS-160NPerformance ParametersDetection Height10-50 m (CNS-MS-30N)Detection Range±75 mmDetection Accuracy3 mmNumber of Output Digital Quantity Points16 - bit digital quantityDistance Between Detection Points10 mmSensor Sensitivity0-9 L
View Details
ModelPCOPCO-MG-CNS-MGS-080NPerformance ParametersDetection Height10-50 m (CNS-MS-30N)Detection Range±70 mmDetection Accuracy3 mmNumber of Output Digital Quantity Points16 - bit digital quantityDistance Between Detection Points20 mmSensor Sensitivity0-9 L
