Reach Stacker 1.4T

The Reach Stacker 1.4T is a high-performance automated guided forklift with a 1,400 kg load capacity and a maximum lifting height of 1,600 mm, designed for efficient and flexible operation in narrow warehouse spaces.

Reach Stacker 1.4T
Reach Stacker 1.4T

Precision Motion Control

Servo System

Compact Navigation

Narrow Aisle 2m±

Flexible Handling

Closed/Open Pallets/Cage/Racks

Proven Drive Systems

Curtis/ZAPI/Kinco Drive

Advanced Positioning

Encoder Options

Smart Detection

Pallet Recognition Sensor Optional

ModelAB-FLB-RS14
Feature
Power TypeElectric
Driving StyleAGV
Rated Load Capacity (Q)1400 kg
Load Center Distance (C)500 mm
Front Suspension Distance (x)130 mm
Wheelbase (Y)1170 mm
Weight
Self Weight (Including Battery)1890 kg
Bridge Load at Full Load, Driving Side/Load-Bearing Side1316/1974 kg
Bridge Load When Unloaded, Driving Side/Load-Bearing Side1323/567 kg
Wheel
Tire TypePolyurethane
Tire Size, Drive WheelΦ 230×75 mm
Tire Size, Load-Bearing WheelsΦ115×55 mm
Tire Size, Balance WheelΦ210×85 mm
Number of Wheels, Drive Side (x=Drive Wheels)/Load-Bearing Side1x-2/2
Track Width, Drive Side (b10)520 mm
Track Width, Load-Bearing Side (b11)970 mm
Basic Dimensions
Total Height (h1)2120 mm
Total Width1184 mm
Total Length (l1)1881 mm
Vehicle Length (Excluding Fork) (l2)841 mm
Free Lifting Height (h2)0 mm
Lifting Height (h3)1600 mm
Max. Lifting Height3000 mm
Door Frame Deployment Height (h4)2188 mm
Fork Surface Min. Height(When the Fork is at Its Lowest) (h5)45 mm
Charging Pad Height (h6)500 mm
Fork Size (L/E/S)1050/120/40 mm
Fork Outer Width (b5)620 mm
Min. Ground Clearance of the Vehicle Body (m1)32 mm
Min. Turning Radius (Wa)1481 mm
Min. Right Angle Stacking Channel Width2033+200 mm
Right Angle Stacking Aisle Width, Pallet 800×1200/
Right Angle Stacking Aisle Width,Pallet 1000×10002097+200 mm
Right Angle Stacking Channel Width, Pallet 1000×1200/
Performance
Driving Speed, Full Load/Empty Load5/5 km/h
Lifting Speed, Full Load/Empty Load115/170 mm/s
Descent Speed, Full Load/Empty Load114/114 mm/s
Climbing Performance, Full Load/Empty Load3%/5%
Driving Brake ModeElectromagnetic braking
Motor
Drive Motor Power2.2 kW
Power of Lifting Motor3.0 kW
Steering Motor Power0.4 kW
Drive Motor Type24 V asynchronous AC motor
Steering Motor Type24 V DC Servo motor
Lifting MechanismHydraulic control
Communication ProtocolCAN
Battery
Weight of Battery58 kg
Battery TypeLithium iron phosphate
Battery Voltage/Rated Capacity24/210 V/Ah








Frequently Asked Questions

What is the PCOPCO Reach Stacker 1.4T Industrial AGV component?

This is a specialized stacker truck AGV component under the PCOPCO brand. It is engineered to power automated lifting and stacking tasks for industrial automated guided vehicle systems. It acts as a core functional module for stacker-type AGVs in material handling workflows.

What key technical parameters does the PCOPCO Reach Stacker 1.4T AGV component have?

The PCOPCO Reach Stacker 1.4T AGV component has a rated load capacity of 1400kg and a maximum lifting height of 3000mm. It is equipped with a 24V210Ah battery and supports BMS communication via RS485 or CAN protocols, matching most mainstream industrial AGV control systems.

In which industrial scenarios is the PCOPCO 1.4T Reach Stacker AGV component applicable?

This PCOPCO AGV component is ideal for narrow-channel material stacking and handling in factories, warehouses and distribution centers. It is commonly used in automotive parts manufacturing, e-commerce warehousing and bulk material transfer operations. Its compact design also suits confined workshop spaces.

How does the PCOPCO Reach Stacker 1.4T AGV component compare to competing products?

Compared to similar industrial AGV components, the PCOPCO model offers two optional BMS communication protocols for wider compatibility with existing control systems. It also features a high-capacity battery for longer continuous operation and precise load matching for 1.4T stacking tasks. The brand’s consistent manufacturing standards also ensure lower long-term failure rates.

What preparations should I make before purchasing the PCOPCO 1.4T Reach Stacker AGV component?

Before purchasing, you should confirm that your existing AGV control system supports either RS485 or CAN communication protocols for BMS matching. You also need to verify that your required lifting height and load capacity align with the component’s 3000mm max height and 1400kg rated load. You can also consult PCOPCO’s official support channels for custom adaptation suggestions if needed.

What exactly is the PCOPCO Reach Stacker 1.4T Industrial AGV component?

The PCOPCO Reach Stacker 1.4T is a specialized AGV component tailored for stacker truck applications. It automates pallet stacking and material handling tasks in industrial environments, working with compatible AGV systems to streamline operational workflows.

What are the key technical specifications of the PCOPCO Reach Stacker 1.4T AGV component?

This PCOPCO Reach Stacker 1.4T has a rated load capacity of 1400kg and a maximum lifting height of 3000mm. It is equipped with a 24V210Ah battery and supports both RS485 and CAN communication via its BMS. These specifications meet most standard industrial material handling demands.

What industrial scenarios is the PCOPCO Reach Stacker 1.4T AGV component suitable for?

This PCOPCO Reach Stacker 1.4T is ideal for warehouses, manufacturing workshops and logistics distribution centers. It performs well in narrow aisle environments requiring automated pallet stacking and transport. It supports consistent, repeatable material handling for high-volume industrial operations.

How does the PCOPCO Reach Stacker 1.4T AGV component compare to similar products on the market?

Compared to many competing AGV stacker components, the PCOPCO Reach Stacker 1.4T offers dual BMS communication protocols for broader system compatibility. Its 24V210Ah battery delivers longer runtime between charges, reducing operational downtime. It also maintains stable performance at its full rated load capacity.

What pre-purchase preparations are needed when buying the PCOPCO Reach Stacker 1.4T AGV component?

Before purchasing this component, first confirm its technical parameters match your operational needs such as load capacity and lifting height. You should also verify compatibility with your existing AGV control systems. For bulk orders, you can contact our sales team for tailored quotations and delivery support.

What is the PCOPCO Reach Stacker 1.4T AGV component?

The PCOPCO Reach Stacker 1.4T is a specialized stacker truck AGV component for industrial automated material handling. It falls under the industrial AGV components category, tailored for medium-duty logistics and stacking tasks.

What are the core technical parameters of the PCOPCO Reach Stacker 1.4T?

This AGV component has a rated load capacity of 1400kg and a maximum lifting height of 3000mm. It is equipped with a 24V210Ah battery and supports BMS communication via RS485 or CAN interfaces. These specs align with standard medium-duty industrial stacking requirements.

What application scenarios is the PCOPCO Reach Stacker 1.4T suitable for?

This PCOPCO AGV component is ideal for medium-duty material stacking and handling in factories, warehouses and compact logistics hubs. It excels at automated pallet stacking at heights up to 3000mm in confined industrial workspaces.

How does the PCOPCO Reach Stacker 1.4T compare to similar AGV stacker components?

Compared to competing industrial AGV stacker components, the PCOPCO model offers flexible BMS communication options for easy system integration. Its 24V210Ah battery delivers reliable runtime for multi-shift operations, and its 1400kg rated load balances performance and cost efficiency.

What should I consider when purchasing the PCOPCO Reach Stacker 1.4T AGV component?

When purchasing this component, first confirm its rated load and lifting height match your on-site material handling needs. Verify compatibility with your existing automated system via its RS485 or CAN communication ports. You can consult PCOPCO’s official team for tailored support for your specific production setup.

What is the PCOPCO Reach Stacker 1.4T industrial AGV component?

This is a purpose-built stacker truck AGV component manufactured by PCOPCO, categorized under industrial AGV parts. It is designed to integrate with automated guided vehicle systems to perform pallet stacking and transportation tasks. It serves as a core module for unmanned industrial material handling workflows.

What are the official technical specifications of the PCOPCO Reach Stacker 1.4T?

Its rated load capacity is 1400kg, with a maximum lifting height of 3000mm. It is equipped with a 24V210Ah battery and supports BMS communication via RS485/CAN interfaces. These specs are optimized for stable and precise industrial material handling operations.

What industrial applications is the PCOPCO Reach Stacker 1.4T suitable for?

This AGV component is ideal for warehouses, manufacturing workshops and logistics distribution centers. It excels at stacking and moving palletized goods within automated material handling workflows. It also fits well in narrow-aisle operations common in modern industrial facilities.

How does the PCOPCO Reach Stacker 1.4T compare to similar AGV components on the market?

Compared to competing products, the PCOPCO Reach Stacker 1.4T offers dual BMS communication options for flexible system integration. Its 24V210Ah battery delivers consistent lifting performance across extended operational shifts. It also features a compact design suited for confined workspace environments.

What key considerations should I have when purchasing the PCOPCO Reach Stacker 1.4T?

Procurement teams should first confirm compatibility between this component and their existing AGV system specifications. They can consult authorized PCOPCO distributors for details on delivery lead times and after-sales support. It is also advisable to verify compliance with local industrial material handling standards.
